Chips in the category 'MPU'

nr name description manufacturer
Alpha See 21064, 21066, 21068, Family DEC*, Mitsubishi, Samsung
Athlon Official name of AMD's successor to the K6, earlier codenamed K7. At it's arrival in 1999 the highest tacted processor around (700 Mhz) AMD*
Butterfly MPU, Family ARM
Capstone See MYK-80 Cryptographic processor (ARM6), Family ARM
Clipper But later also a Cryptographic processor (ARM6), Family , see MYK-78E, MYK-78T, MYK-77. ARM
Clipper MCU from Fairchild, later adopted by workstation manufacturer Intergraph after Fairchild was bought by NS. Fairchild*
Deerfield 3th successor of Intel's Merced. It will probably be a more economical version of the Merced, McKinley or Madison. Intel
GVSC See 1750 IBM
HPC* (High Performance Computer), 16-Bit MCU family, See 46003, 46083, 46100, 46164, 46400 NS*
Hobbit 32-bit Stack Oriented RISC CPU, discontinued unfortunately AT&T/NCR
MIPS See 10000, 3000, 4000, 4200, 4400, 4600, 8000 MIPS
MISC (Minimal Instruction Set Computer), Forth oriented processor, see F21, www.m-i-s-c.net/ Ultra Technology
Madison Faster version of the McKinley using 0.13 micron technology. Intel*
Mantis MPU, Family ARM
McKinley The first successor of the Merced: Using 0.18 micron copper technology and faster than 1 Ghz, according to Intel on 19981014. Intel*
Merced The still long awaited 64 bits processor by Intel. Rumour has it that it's release is so much delayed that it's successor will be introduced earlier then the Merced itself... ;-). Merced will probably use 0.18 micron non-copper technology. It's introduction is now (=199812) expected in 1999q4. The successors are planned to be the McKinley, Madison and Deerfield, Critical comparison with existing processors and DSP's Intel*
MicroSparcII Sparc processor from SUN SUN
P5 Pre-release code name for the i586, now known as Pentium, Family Intel*
P6 Pre-release code name for the i686, Family Intel*
P7 Pre-release code name for the i786, Announcement, Family Intel*
P8 Pre-release code name for the i886, Family , Intel*, HP*
PACE See 1750 Performance
Pentium See also 80586, Family Intel
PowerPC See 601, 602 (?), 603, 604, 620, Family Motorola, IBM, Apple
RubyII VPS10101 (ARM6) MCU, Family ARM
Sparc See 7600, 7601, 7603, 7608, 7153, 7181 and .. (?), Design-experiences-with SUN*
Spider MPU, Family ARM
SuperSparcII Sparc processor SUN
Transputer See 212, 414, 800, 9000 etc., I-set, About Newslist, www.afm.sbu.ac.uk/transputer/ INMOS*
UltraSparc Sparc processor from SUN. Sun Microsystems, Inc. announced (199811) the availability of samples of the 400-MHz version of the UltraSPARC-II microprocessor and the plans for the 450-MHz version to be available in the Spring of 1999, www.sun.com/smi/Press/sunflash/9811/sunflash.981102.2.html SUN
Xeon Advanced 450 MHz Pentium II. Intel
CompactRISC a 16 bit Embedded applications RISC family, www.national.com/appinfo/compactrisc/ NS*
Itanium Final name for Intel's 64 bit Merced processor Intel*
MISC MPU, www.m-i-s-c.net/ Ultra Technology*
Nios soft core embedded processor, with new simultaneous multi-master bus architecture to optimize data flow in high-bandwidth applications, easy integration of user-defined processor instructions to accelerate program execution, world-class debugging solutions using an on-chip debug peripheral for real-time debugging and software trace and SDRAM* interface and memory controller peripherals, data Altera*
1000 PSC1000 The only 32bit forth like CPU I know of is the PSC1000, www.ptsc.com/ PTSC*
10000 R10000 RISC-family processor (T5), www.mips.com/HTMLs/T5_B.html MIPS*
105 MPC105 PowerPC PCI Bridge/Memory Controller: Single chip PCI bridge, level 2 cache controller and a DRAM interface.
106 MPC106 PowerPC PCI Bridge/Memory Controller: Single chip PCI bridge, level 2 cache controller and a DRAM interface.
11 J-11 16-Bit MPU (PDP-11/70 Compatible), Card DEC*
11 LSI-11 16-Bit MPU family (PDP-11 Compatible), Card DEC*
11 T-11 16-Bit MPU (PDP-11 Compatible), Card DEC*
110 SA-110 'StrongARM' Low power, hi-perf Risc* MPU ARM*, DEC*, Intel
1100 SA-1100 member of the high-performance, low-power StrongARM family since 199709. Press release DEC, ARM*
146805 MC146805 CMOS* 8-bit MPU Motorola*
16 CR16 Compact Risc*, www.national.com/appinfo/cr16/ NS*
16000 MCSP16000 16BIT RISC CPU processor core MCS Logic
16008 Former name of the 32008 NS
16016 Former name of the 32016 NS
16032 Former name of the 32032 32-Bit MPU, Card NS*
180 AB180 Z180 compatible processor at 20 MIPS, www.ab-semicon.com/products/ab180-20.pdf AB-Semicon
180 Z180 MPU Zilog
1800 CDP1800 see the link, www.intersil.com/micro/up1802.asp Intersil
1802 CDP1802 CMOS* 8-Bit COSMAC MPU, Card RCA*
1802 CDP1802 see the link, www.intersil.com/micro/up1802.asp Intersil
1802 CDP1802ACD CDIP40 -40+85C 3.2MHz 5.0V 8 bit MPU Harris $16/1K
1802 CDP1802ACDX CDP1802ACD with 160 hour +125C burn-in Harris $20/1K
1802 CDP1802ACE CDIP40 -40+85C 3.2MHz 5.0V 8 bit MPU Harris $4/1K
1802 CDP1802ACEX CDP1802ACE with 160 hour +125C burn-in Harris $5/1K
1802 CDP1802ACQ PLCC44 -40+85C 3.2MHz 5.0V 8 bit MPU Harris $5/1K
1802 CDP1802BCDX CDP1802BCD with 160 hour +125C burn-in Harris $31/1K
1802 CDP1802BCE PDIP40 -40+85C 5.0MHz 5.0V 8 bit MPU Harris $6/1K
1802 CDP1802BCEX CDP1802BCE with 160 hour +125C burn-in Harris $8/1K
1802 CDP1802BCQ PLCC44 -40+85C 5.0MHz 5.0V 8 bit MPU Harris $8/1K
1802 CDP1802CD CDIP40 -40+85C 2.5MHz 5.0V 8 bit MPU Harris $19/1K
1802 CDP1802CE CDIP40 -40+85C 2.5MHz 5.0V 8 bit MPU Harris $5/1K
1802 CDP1802CEX CDP1802CE with 160 hour +125C burn-in. Harris $6/1K
18023 CDP1802ACD3 SBDIP40 MIL-STD-883 NON COMPLIANT (5V) Harris $34/1K
18023 CDP1802AD3 SBDIP40 MIL-STD-883 NON COMPLIANT (10V) Harris $43/1K
1805 CDP1805 see the link, www.intersil.com/micro/up1802.asp Intersil
1805 CDP1805ACD CDIP40 -40+85C 5.0V 5.0MHz 8 bit MPU Harris $23/1K
1805 CDP1805ACDX CDIP40 -40+85C 5.0V 5.0MHz 8 bit MPU 160 hour +125C burn-in Harris $45/1K
1805 CDP1805ACE PDIP40 -40+85C 5.0V 5.0MHz 8 bit MPU Harris $12/1K
1805 CDP1805ACQ PLCC44 -40+85C 5.0V 5.0MHz 8 bit MPU Harris $16/1K
1806 CDP1806 see the link, www.intersil.com/micro/up1802.asp Intersil
1806 CDP1806ACD CDIP40 -40+85C 5.0V 5.0MHz 8 bit MPU Harris $38/1K
1806 CDP1806ACE PDIP40 -40+85C 5.0V 5.0MHz 8 bit MPU Harris $10/1K
1806 CDP1806ACEX PDIP40 -40+85C 5.0V 5.0MHz 8 bit MPU 160 hour +125C burn-in Harris $13/1K
1806 CDP1806ACQ PLCC44 -40+85C 5.0V 5.0MHz 8 bit MPU Harris $13/1K
186 Am186EM PDF PS AMD*
188 Am188EM PDF PS AMD*
20 V20 MPU (D70108) (=8088+) NEC*
21 F21 MISC Stack processor - Forth Engine, Preliminary Specs, www.m-i-s-c.net/ UT*
21064 CPU from 2106x-family (Alpha), Text DEC*
21066 CPU from 2106x-family (Alpha), Text DEC*
21068 CPU from 2106x-family (Alpha), Text DEC*
210xx CPU-family (Alpha), www.digital.com, Offerman DEC*
212 16-Bit CPU (Transputer) Inmos*
2650 8-Bit MPU, Card Signetics*
280 MPU Zilog
29000 Am29000 RISC CPU, Incl, PDF PS AMD*
29005 Am29005 RISC CPU, Incl, PDF PS AMD*
29030 Am29030 RISC CPU, PDF PS, PDF PS, PDF PS AMD*
29035 Am29035 RISC CPU, PDF PS, PDF PS, PDF PS AMD*
29040 Am29040 RISC CPU, PDF PS AMD*
29050 Am29050 RISC processor, PDF PS AMD*
29116 Am29116A High-Performance 16-Bit Bipolar Microprocessor AMD
29116 Am29L116A High-Performance 16-Bit Bipolar Microprocessor AMD
29117 Am29117 High-Performance 16-Bit Bipolar Microprocessor AMD
30 V30 CPU (=8086+) (D70116) NEC*
3000 R3000 RISC processor, www.mips.com/HTMLs/R3000_B.html MIPS*
32000 CPU family NS
32008 32-Bit CPU with 8-Bit data bus, pinout NS*
32016 32-Bit CPU with 16-Bit Data bus, pinout, Card NS*
32032 32-Bit CPU with 32-Bit Data bus, Card NS*
32080 quad* 32-Bit Integer DSP*, 32-Bit RISC CPU, 100-Mflops* FPU, 50k*8 SRAM*, transfer controller, video controller (~$350, 1995) TI*
32332 Second generation 32-Bit CPU NS
32532 High performance 32-Bit CPU NS
380 Z380 16/32-Bits version of the Z80 CPU at 40 MHz Zilog* $10/100k
386 VM386SX+ 386SX compatible CPU VMT*
4000 R4000 RISC-Processor-family MIPS*
4004 i4004 First CPU, Email, Pinout_and_iset, www.teleport.com/~prp/collect/i4004 = four pages from 1975 databook Intel*
4101 VR4101 MIPS 4000 processor NEC
414 IMS414 32-Bit CPU (Transputer), I-set Inmos*
4200 R4200 RISC processor, www.mips.com/HTMLs/R4200_B.html MIPS*
4400 R4400 RISC processor, www.mips.com/HTMLs/R4400_B.html MIPS*
4600 R4600 RISC processor, mips.com/.. QED*, MIPS
4650 R4650 RISC processor, mips.com/.. QED*, MIPS
4700 R4700 RISC processor, mips.com/.. QED*, MIPS
486 i486 See 80486 Intel*
4862 VM486DLC2 486DLC compatible CPU VMT*
586 CPU from the 8086-family, Intel name: Pentium (for copyright reasons), (=486+), see also 80586, Family AMD, Intel*
5962 5962-8601601QA SMD 80C88 8/16 bit CPU 5MHz CDIP40 Harris $132/1K
5962 5962-8601601XA SMD 80C88 8/16 bit CPU 5MHz LCC44 Harris $181/1K
5962 5962-9067801MXC SMD PGA68 -55+125C 5.0V 10.0MHz 16 bit CPU MIL-STD-883C Harris $265/1K
5962 5962-9067802MXC SMD PGA68 -55+125C 5.0V 12.5MHz 16 bit CPU MIL-STD-883C Harris $285/1K
6 ARM6 32-Bit MPU-RISC Core, Family ARM*, VTI
6 K6 AMD's version of the Pentium Pro, data AMD*
6 P6 Preliminary name of the i686, 80686 (=Pentium+), was later named Pentium Pro Intel*
60 ARM60 32-Bit MPU-RISC Core, Family ARM*, VTI
60 ARM60L General purpose 32-bit MPU, 30 MIPS, 305mW at 33MHz, 5V, Based on the ARM6 core, Family ARM*
60 ARM60b Quick, low-power MPU, Family GPSI*
601 1st Generation PowerPC RISC MPU for desktop computers, Family IBM*, Motorola
601 PowerPC601 The first member of the family providing economical performance for powerful desktop PCs. Motorola, IBM?
602 PowerPC RISC MPU for cost sensitive applications IBM*, Motorola
603 PowerPC RISC MPU, low power, Family IBM*, Motorola
603 PowerPC603 Family A low-power, low-cost design also ideal for embedded applications requiring high performance Motorola, IBM?
603 PowerPC603 Family Workstation-level performance packed into a low-power, low-cost design ideal for desktop computers, notebooks, and battery-powered systems. Motorola, IBM?
604 2nd generation PowerPC RISC MPU for desktop computers, Family IBM*, Motorola
604 PowerPC604 Family An advanced superscalar engine with multiprocessing support for sophisticated PCs and servers. Motorola, IBM?
61 ARM61 32-Bit MPU-RISC Core, never made!, Family ARM*, VTI
610 ARM610b Quick, low-power MPU, Family GPSI*
620 High performance 64-bit PowerPC RISC MPU for servers and workstations, Family IBM*, Motorola
620 PowerPC620 A full 64-bit implementation providing ultrahigh performance for multiprocessing servers and supercomputers Motorola, IBM?
6303 CPU (=6803?), pinout, I-set Hitachi*
6309 CPU (=6809+), Family Hitachi
63701 hd63701xop mpu* hitachi 8 bit 1.5mhz Hitachi
6500 R6500 8-Bit CPU Rockwell*
6501 R6501 8-Bit MPU, 650x-Card Rockwell*
6502 R6502 8-Bit MPU, 650x-Card, 6502-Card (databus may be in reverse order), 65C02-Card (databus may be in reverse order) Rockwell, UMC
6502 W6502 8-Bit MPU, 650x-Card, 6502-Card (databus may be in reverse order), 65C02-Card (databus may be in reverse order) Rockwell, UMC, WDC*
6502 W65C02S MPU, www.westerndesigncenter.com/chips.html WDC
6502 um6502a microprocessor 8 bit cpu* 2mhz UMC
6503 R6503 8-Bit MPU, Card Rockwell*
6504 R6504 8-Bit MPU, Card Rockwell*
6505 R6505 8-Bit MPU, Card Rockwell*
6507 R6507 8-Bit MPU UMC
6510 6510 similar to the 6502
6512 R6512 8-Bit MPU UMC
65816 W65C816S 8-Bit MCU (=~6502), www.westerndesigncenter.com/ch816S.html WDC
6800 MC6800 8-Bit CPU, 6800, 680x-Card Motorola
68000 68000 16 bits processor, DIP64 Motorola
68000 MC68000 16-Bit CPU, I-set, Family , Card Motorola*, Hitachi
68000 MC68000G10 Atari: CPU 68000 at 10MHz in plastic Motorola
68000 MC68000P8 Atari: CPU 68000 at 8MHz in plastic Motorola
68000 SCN68000 Atari: CPU 68000 at 8MHz ceramic with messing plate Philips
68000 SCN68000C8N64 Atari: CPU 68000 at 8MHz in plastic Philips
68000 ST68000 Atari: CPU 68000 at 8MHz in plastic ST?
68000 TS68000 16-Bit HMOS MPU, 8, 10 and 12 MHz MPU, 32 bit internal structure PDIP64, PLCC68 ST
6800010 ts68000cp10 micro* 16 bit 10mhz ST
6800012 ts68000cp12 mpu* 16 bit 12mhz ST
6800016 ts68000cp16 mpu* 16 bit 16mhz ST
68001 MC68001 16-Bit CPU, low power Motorola*
68008 MC68008 16-Bit CPU, 8-Bit bus (=68000-), Family , Card Motorola*
6801 MC6801 8-Bit CPU (=6800+128 RAM+2K ROM), 6801, 680x-Card Motorola*
68010 MC68010 32-Bit int/16-Bit ext CPU with virtual memory (=68000+), Family , Card Motorola*
6802 MC6802 8-Bit MPU (=6800+128 RAM), pinout, 6802, 680x-Card Motorola*
6802 ef6802p mpu*+clock+ram* 1mhz ST
68020 MC68020 32-Bit int/32-Bit ext CPU (=68000+), Family Motorola*
6803 MC6803 CPU (=6800+128 RAM) *pinout, 6803, 680x-Card Motorola*
68030 MC68030 32-Bit CPU with MMU* (=68000+), Family Motorola*
68034 EF6803U4 8-Bit NMOS* MPU, 6803 With 192 RAM, 1 MHZ PDIP40 ST
68034 EF68A03U4 8-Bit NMOS* MPU, 68A03 With 192 RAM, 1.5 MHz PDIP40 ST
68040 MC68040 32-Bit CPU with MMU*, cache and floating point (=68000+), Family Motorola*
68060 MC68060 32-Bit CPU, superscalar (=68000+), Family Motorola*
6808 MC6808 8-Bit MPU (RAMless 6802), 6808-Card, Card Motorola*
6809 EF6809 8-Bit NMOS* MPU, High Performance MPU, 1 MHz PDIP40 ST
6809 EF6809E 8-Bit NMOS* MPU, 6809 With External Clock, 1 MHz PDIP40 ST
6809 EF68A09 8-Bit NMOS* MPU, High Performance MPU, 1.5 MHz PDIP40 ST
6809 EF68A09E 8-Bit NMOS* MPU, 68A09 With External Clock, 1.5 MHz PDIP40 ST
6809 EF68B09 8-Bit NMOS* MPU, High Performance MPU, 2 MHz PDIP40 ST
6809 EF68B09E 8-Bit NMOS* MPU, 68B09 With External Clock, 2 MHz PDIP40 ST
6809 MC6809 8-Bit CPU, Family Motorola
6816 MC6816 6811 Source Code Compatible CPU Motorola*
68330 MC68330 Integrated CPU32 processor, Family Motorola*
686 i686 (i686, 80686) Logical name for P6, (=Pentium+) Intel*
68701 MC68701 8-Bit CPU Motorola
68705 MC68705 One-time programmable version of the 6805 Motorola*
68711 MC68711 One-time programmable version of the 6811, Family Motorola*
7 P7 Preliminary name of the i786, 80786 (=P6+) Intel*
74610 LH74610 ARM610, Family Sharp
74710 LH74710AM ARM710, Family Sharp
7600 Sparc RISC processor family Cypress, SUN
7601 Sparc-family Integer Unit Cypress, SUN
780 D780C-1 Z80 like CPU, Family NEC*
7810 7810 MPU, Family NEC*
786 i786,80786 Logical name for P7, (=P6+) Intel*
793000 IDT79R3000A RISC CPU Processor, 2040MHz, on-chip Cache Control, 175 PGA NOW 2860 J 5.1 Memory Management Unit, 64-Entry Translation Lookaside Buffer, thirty-two 32-bit general-purpose registers. IDT*
793010 IDT79R3010A RISC Floating-Point Accelerator, 20-40MHz 84 PGA NOW 2873 J 6.1 IDT*
793041 IDT79R3041 RISController, 2.5KB cache, R3000A core, 4-deep 84 PLCC NOW 2905 J 5.2 IDT*
793041 IDT79RV3041 read/write buffers, low-cost packaging, pin-compatible with 100 PF R3051/52/71/81, 16-25MHz. IDT*
7930512 IDT79R3051/2 RISControllers, 6KB or 10KB on-chip cache, R3000A CPU core, 84 PLCC NOW 2874 J 5.3 and 4-deep read/write buffers, low-cost 84-pin plastic packaging, 84 MJ 20-40MHz. IDT*
793071 IDT79R3071 RISController, 20KB on-chip cache, R3000A CPU core, 4-deep 84 MJ NOW 3045 J 5.4 read/write buffers, pin-compatible with R3051/52/41/81, 33-50MHz. IDT*
793081 IDT79R3081 RISController, 20KB on-chip cache, R3000 CPU core, 84 MJ NOW 2889 J 5.5 IDT*
793081 IDT79RV3081 R3010A Floating Point Accelerator, 4-deep read/write buffers, pin-compatible with R3051/52/41/71, 20-50MHz. IDT*
793500 IDT79R3500 RISCore integrates R3000A CPU and R3010A FPA using 161 PGA NOW the R3000A pinout. IDT*
7936100 IDT79R36100 Integrated RISController, 5KB cache, R3000A core, flexible bus 208 PQFP June interface, controllers and peripherals at 16-33MHz. IDT*
794400 IDT79R4400 Very high-performance, highly integrated 64-bit CPU, fully binary- 447 PGA NOW 2884 J 5.6 IDT*
794400 IDT79RV4400 compatible with the R3000A. Combines CPU, floating-point and 179 PGA 32KBof cache, capable of over 80 VAX mips* sustained performance IDT*
794600 IDT79R4600 Very high-performance, highly integrated 64-bit CPU, fully binary- 179 PGA NOW 3038 J 5.7 IDT*
794600 IDT79RV4600 compatible with the R3000A optimized for low-cost systems. 208 MQUAD Combines CPU, floating-point and 32KB of cache. IDT*
794650 IDT79R4650 High-performance, highly integrated 64-bit CPU, fully binary- 208MQUADMarch compatible with the R3000A optimized for embedded systems. Includes CPU, new multiply and atomic "multiply-add" enhancements and 16KB of cache. IDT*
794700 IDT79R4700 Very high-performance, highly integrated 64-bit CPU, fully binary- 208 MQUAD March compatible with the R3000A optimized for multi-media 179 PGA applications. Includes CPU, improved R4600 FPA, two-way set associative caches and 32KB of cache. IDT*
8 P8 Preliminary name of Intel's i886, 80886 (=P7), will include RISC-processor from HP Intel*, HP
80 Z80 See 8400 Zilog
80 Z80-B-CPU 6 MHz Zilog MPU order from Barend
80 Z80-B-SIO-0 serial port? 6 MHz order from Barend
800 NSC800 8-Bit CMOS* MPU (=~Z80), Card NS, SMC
800 Z800 See 8108, 8116 Zilog*
8000 MCSP8000 8BIT CISC* CPU processor core MCS Logic
8000 PA-8000 Fully 64-bits PA-RISC mpu* HP*
8000 R8000 RISC-family processor (TFP), www.mips.com/HTMLs/R8000_B.html MIPS*
8000 Z8000 16/32-Bit MPU family, Z8000 Zilog*
80000 Z80000 Central processing unit (never released?) Zilog*
8001 Z8001 16/32-Bit segmented MPU, Z8001-Card, Z8000-Card Zilog*
8002 Z8002 16/32-Bit nonsegmented MPU, Z8002-Card, Z8000-Card Zilog*
8002 Z8002 Z8000 MPU ST
8003 Z8003 16/32-Bit virtual memory MPU Zilog*
8004 Z8004 16/32-Bit virtual memory MPU Zilog*
8008 8-bit MPU predecessor of the 8080 Intel
80180 Z180,Z80180 MPU Zilog
80186 16-bit MCU (=8086+) Intel*
80186 iAPX80186 High Integration 16-Bit Microprocessor AMD
80188 16-bit MCU (=8088+ Intel*
80286 16-bit MPU (=8086+), See also 286 Intel*, many
80286 CG80C286-12 PGA68 0+70C 5.0V 12.5MHz 16 bit CPU Harris $38/1K
80286 CG80C286-16 PGA68 0+70C 5.0V 16.0MHz 16 bit CPU Harris $41/1K
80286 CG80C286-20 PGA68 0+70C 5.0V 20.0MHz 16 bit CPU Harris $47/1K
80286 CS80C286-12 PLCC68 0+70C 5.0V 12.5MHz 16 bit CPU Harris $13/1K
80286 CS80C286-1296 PLCC69 0+70C 5.0V 12.5MHz 16 bit CPU (tape and reel) Harris $13/1K
80286 CS80C286-16 PLCC68 0+70C 5.0V 16.0MHz 16 bit CPU Harris $15/1K
80286 CS80C286-1696 PLCC69 0+70C 5.0V 16.0MHz 16 bit CPU (tape and reel) Harris $15/1K
80286 CS80C286-20 PLCC68 0+70C 5.0V 20.0MHz 16 bit CPU Harris $17/1K
80286 CS80C286-2096 PLCC69 0+70C 5.0V 20.0MHz 16 bit CPU (tape and reel) Harris $17/1K
80286 CS80C286-25 PLCC68 0+70C 5.0V 25.0MHz 16 bit CPU Harris $18/1K
80286 CS80C286-2596 PLCC69 0+70C 5.0V 25.0MHz 16 bit CPU (tape and reel) Harris $18/1K
80286 IAPX80286 High Performance Microprocessor with Memory Management and Protection AMD
80286 IG80C286-10 PGA68 -40+85C 5.OV 10.0 MHz 16 bit CPU Harris $43/1K
80286 IG80C286-12 PGA68 -40+85C 5.0V 12.5 MHz 16 bit CPU Harris $47/1K
80286 IS80C286-10 PLCC68 -40+85C 5.0V 10.0MHz 16 bit CPU Harris $17/1K
80286 IS80C286-12 PLCC68 -40+85C 5.0V 12.5 MHz 16 bit CPU Harris $17/1K
80286 IS80C286-16 PLCC68 -40+85C 5.0V 16.0MHz 16 bit CPU Harris $22/1K
80286 IS80C286-20 PLCC68 -40+85C 5.0V 20.0MHz 16 bit CPU Harris $26/1K
80286 MG80C286-10/883 PGA68 -55+125C 5.0V 10.0MHz 16 bit CPU MIL-STD-883C Harris $265/1K
80286 MG80C286-12/883 PGA68 -55+125C 5.0V 12.5MHz 16 bit CPU MIL-STD-883C Harris $285/1K
80386 32-Bit MPU (=80286+), Family Intel*
80486 32-Bit MPU (=80386+), Family Intel*
80501 i80501 Official product code for the Pentium I 60 and 66 MHz Intel
80502 i80502 Official product code for the Pentium I 50/75, 60/90, 66/100, 60/120 en 66/133 etc. without MMX Intel
80503 i80503 Official product code for the Pentium I with MMX Intel
8050366 i8050366 Official product code for the Pentium with MMX and 66 MHz external bus Intel
80586 The official Pentium product codes are 80501 (pentium I 60 and 66 MHz) and 80502 (pentium I 50/75, 60/90, 66/100, 60/120, 66/133 etc.), 80503 (pentium I with MMX) AMD, Cyrix, IDT, Intel
80586 ? 32-Bit MPU (Pentium) (=80486+), Family Intel*
8080 i8080A 8-Bit MPU, pinout, 8080A-Card Intel*, many
8085 8-Bit MPU (=8080+), pinout, 8085A-Card Intel*
8085 80C85-AP2 CPU order from Barend
8085 MSM80C85A Oki
8085 i8085 MPU Intel $1
8086 CD80C86 CDIP40 0+70C 5.0V 5.0MHz 16 bit MPU Harris $19/1K
8086 CD80C86-2 CDIP40 0+70C 5.0V 8.0MHz 16 bit MPU Harris $25/1K
8086 CP80C86 PDIP40 0+70C 5.0V 5.0MHz 16 bit MPU Harris $10/1K
8086 CP80C86-2 PDIP40 0+70C 5.0V 8.0MHz 16 bit MPU Harris $13/1K
8086 CS80C86 PLCC44 0+70C 5.0V 5.0MHz 16 bit MPU Harris $11/1K
8086 CS80C86-2 PLCC44 0+70C 5.0V 8.0MHz 16 bit MPU Harris $14/1K
8086 ID80C86 CDIP40 -40+85C 5.0V 5.0MHz 16 bit MPU Harris $27/1K
8086 ID80C86-2 CDIP40 -40+85C 5.0V 8.0MHz 16 bit MPU Harris $35/1K
8086 IP80C86 PDIP40 -40+85C 5.0V 5.0MHz 16 bit MPU Harris $14/1K
8086 IP80C86-2 PDIP40 -40+85C 5.0V 8.0MHz 16 bit MPU Harris $18/1K
8086 IS80C86 PLCC44 -40+85C 5.0V 5.0MHz 16 bit MPU Harris $17/1K
8086 IS80C86-2 PLCC44 -40+85C 5.0V 8.0MHz 16 bit MPU Harris $22/1K
8086 MD80C86-2/883 CMOS* 16 bit CPU MIL 8MHz CDIP40 Harris $128/1K
8086 MD80C86-2/B CMOS* 16 bit CPU MIL 8MHz CDIP40 Harris $112/1K
8086 MD80C86/B CMOS* 16 bit CPU MIL 5MHz CDIP40 Harris $98/1K
8086 MR80C86-2/883 CMOS* 16 bit CPU MIL 8MHz LCC44 Harris $293/1K
8086 MR80C86-2/B CMOS* 16 bit CPU MIL 8MHz LCC44 Harris $255/1K
8086 MR80C86/B CMOS* 16 bit CPU MIL 5MHz LCC44 Harris $135/1K
8086 MSM80C86A Oki
8086 i8086 16-Bit MPU from the 80x86-family, pinout, I-set, Gif, Card, amd.com/..(CPU's), amd.com/..(MCU's), Offerman, pinout Intel*, many $1.55
8086883 MD80C86/883 CMOS* 16 bit CPU MIL 5MHz CDIP40 Harris $112/1K
8086883 MR80C86/883 CMOS* 16 bit CPU MIL 5MHz LCC44 Harris $155/1K
8088 16-Bit 8086 MPU with 8-Bit Data Bus, pinout, Card Intel*, many
8088 CD80C88 CDIP40 0+70C 5.0V 5.0MHz 8/16 bit MPU Harris $15/1K
8088 CD80C88-2 CDIP40 0+70C 5.0V 8.0MHz 8/16 bit MPU Harris $20/1K
8088 CP80C88 PDIP40 0+70C 5.0V 5.0MHz 8/16 bit MPU Harris $8/1K
8088 CP80C88-2 PDIP40 0+70C 5.0V 8.0MHz 8/16 bit MPU Harris $10/1K
8088 CS80C88 PLCC44 0+70C 5.0V 5.0MHz 8/16 bit MPU Harris $9/1K
8088 CS80C88-2 PLCC44 0+70C 5.0V 8.0MHz 8/16 bit MPU Harris $12/1K
8088 HCP80C88 MPU CMOS* Harris $1.00
8088 ID80C88 CDIP40 -40+85C 5.0V 5.0MHz 8/16 bit MPU Harris $22/1K
8088 ID80C88-2 CDIP40 -40+85C 5.0V 8.0MHz 8/16 bit MPU Harris $29/1K
8088 IP80C88 PDIP40 -40+85C 5.0V 5.0MHz 8/16 bit MPU Harris $11/1K
8088 IP80C88-2 PDIP40 -40+85C 5.0V 8.0MHz 8/16 bit MPU Harris $15/1K
8088 IS80C88 PLCC44 -40+85C 5.0V 5.0MHz 8/16 bit MPU Harris $14/1K
8088 IS80C88-2 PLCC44 -40+85C 5.0V 8.0MHz 8/16 bit MPU Harris $18/1K
8088 IS80C88-296 IS80C88-2 IN tape and reel Harris $18/1K
8088 IS80C88-2X96 IS80C88-2 IN tape and reel Harris $18/1K
8088 MD80C88-2/883 CMOS* 8/16 bit CPU MIL 8MHz DIP40 Harris $151/1K
8088 MD80C88-2/B CMOS* 8/16 bit CPU MIL 8MHz CDIP40 Harris $151/1K
8088 MD80C88/B CMOS* 8/16 bit CPU MIL 5MHz CDIP40 Harris $110/1K
8088 MR80C88-2/883 CMOS* 8/16 bit CPU MIL 8MHz LCC44 Harris $210/1K
8088 MR80C88-2/B CMOS* 8/16 bit CPU MIL 8MHz LCC44 Harris $210/1K
8088 MR80C88/B CMOS* 8/16 bit CPU MIL 5MHz LCC44 Harris $151/1K
8088 MSM80C88A Oki
8088 i8088 MPU Intel $2.20
8088883 MD80C88/883 CMOS* 8/16 bit CPU MIL 5MHz DIP Harris <$1/1K
8088883 MR80C88/883 CMOS* 8/16 bit CPU MIL 5MHz LCC44 Harris $151/1K
80960 MPU, RISC-processor, www.intel.com/embedded/i960/, www.amc.com/960-mail.htm, Family Intel
8108 Z8108,Z800 MPU (never released?) Zilog*
8116 Z8116,Z800 MPU (never released?) Zilog*
8208 Z8208,Z800 MPU (never released?) Zilog*
821 MPC821 A versatile, single-chip integrated microprocessor and peripheral combination used in portable computing and personal communications products Motorola
8216 Z8216,Z800 MPU (never released?) Zilog*
823 MPC823 This 32-bit integrated chip is optimized for low-power, imaging, and communication products such as digital cameras and other mobile computing devices Motorola
8300 Z8300 Low power Z80 MPU Zilog*
8400 Z8400,Z80 8-Bit MPU, Card Zilog*
84001 Z8400HB1 Z80H MPU ST
8405201 8405201QA SMD 80C86 16 bit CPU 5MHz CDIP40 Harris $108/1K
8405201 8405201XA SMD 80C86 16 bit CPU 5MHz LCC44 Harris $148/1K
8405202 8405202QA SMD 80C86 16 bit CPU 8MHz CDIP40 Harris $154/1K
8405202 8405202XA SMD 80C86 16 bit CPU 8MHz LCC44 Harris $352/1K
8500 8500 similar to the 6502
8510 8510 similar to the 6502
863 VM863S 286 real mode only CPU VMT*
86600 32-Bit RISC MPU, Family ARM, VTI
86610 32-Bit RISC MPU, Family ARM, VTI
867 VM867S 1K cache 50MHz 16bit CPU VMT*
87252 8k*8 CMOS* controller Intel
880 U880 MPU from the former DDR (German Democratic Republic) (=Z80), source: Matthias Bruestle <m@mbsks.franken.de>
8800 Z8800 see Super8 ROM-less Zilog*
8801 Z8801 see Super8 ROM-less Zilog*
88100 32-bit RISC MPU Motorola*
88110 32-bit RISC MPU Motorola*
8820 Z8820 see Super8 8k*8 ROM Zilog*
8822 Z8822 see Super8 8k*8 Protopak Zilog*
886 i886,80886 Logical name for P8, (=P7+), will include RISC processor from HP Intel*, HP
89188 n89c188xl-10 CPU Intel 10mhz plcc pkg AMD
9000 T9000 Transputer CPU Inmos*
9080 8-bit CPU (=8080) AMD
944516 16-Bit MPU NS
960 See 80960 Intel
9900 16-Bit MPU, Card TI*
9940 16-Bit MPU, Card TI*
9980 16-Bit MPU, Card TI*

See also

www.chipcatalog.com/catindex.htm Very nice! Search the site on www.chipsinfo.com/
www.freetradezone.com/ Registration needed
www.icmaster.com/ Registration needed
www.itis.spb.ru/win/map_eng.htm Russian site with a lot of component overviews, large parts are in Russian
cmpmedia.globalspec.com/ This used to be Questlink.com.

Ad for PCI video capturing boards by Dektec.
Goto: Main Mirror About Author
Register: Yourself Company
Feedback: Correction Addition Question
Request quote: Chips (Deutsch) Chips (English) Chips (Nederlands)

Advertisement by Adprov

Viewable with any browser


page modified: 20080306
page compiled: 20080306
site compiled:  Version GIF
